For FOM1800 and FOM2000 options, please send us an email at info@teoarms.com
Main Features
1. Foldable aluminum alloy connecting bridge;
2. Super-wide 120 degree FOV;
3. Improved optics – reduced distortion(less than 1%) and longer eye relief(25-40mm) for enhanced comfort;
4. Enhanced durability – military-grade engineering plastics + aviation aluminum alloy bridge;
5. Removable battery packs (40-80 hours of battery life) with 4pcs CR123 batteries;
6. Available with G24 mount to connect helmet;
7. Build-in IR and low battery indicator;
8. Separately diopter adjusting knob offer offer range +1.5 to -2.5(argus PNVG and L3 GPNVG18 has not this knob)
9. Auto function on full device and each pods, flip up auto shot off, flip down auto turn on;
10. IP65 waterproof, IP67 also can offer;
| Gen2+ Image intensifier tube | ||||
|---|---|---|---|---|
| FOM | FOM1400+ | FOM1600+ | FOM1800+ | FOM2000+ |
| SNR(dB) | ≥23 | ≥25 | ≥28 | |
| Resolution(lp/mm) | ≥60 | ≥64 | ≥68 | |
| Gain(cd/m²/lx) | 8000-12000 | 12000-20000 | ||
| Gen3 Image intensifier tube | ||||
| FOM | FOM1200+ | FOM1400+ | FOM1600+ | FOM1800+ |
| SNR(dB) | ≥22 | ≥25 | ≥28 | |
| Resolution(lp/mm) | ≥51 | ≥55 | ≥60 | ≥64 |
| Gain(cd/m²/lx) | 8000-20000 | 11000-20000 | 12000-20000 | |
| Battery type | CR123 | |||
| Voltage range | 2.6-4.2V | |||
| Switch model | ON/IR/AUTO | |||
| Power | ＜0.2W | |||
| Battery capacity | 800-3200maH | |||
| Working time | 30-80H | |||
| IR illuminator | 850nm 20mW | |||
| IR indicator | Yes | |||
| Optical | ||||
| Magnification | 1X | |||
| FOV | 120±2° | |||
| Optical distortion | 1% Max | |||
| Diopter range | ±5° | |||
| Optical system | F1.18 22.5mm | |||
| Focus range(M) | 0.25–∞ | |||
| Eye relief | 25-40mm Full FOV | |||
| Optical MTF | 120LP/mm | |||
| Structure | ||||
| Focus type | Manual | |||
| IPD range | 50-85mm | |||
| IPD lock type | Manual | |||
| Temperature range | -40℃~+55℃ | |||
| Humidity range | 5%-95% | |||
| Waterproof standard | IP65 | |||
| Size | 155x136x83mm | |||
| Weight | 830g | |||
