Main features:
1. Same optical quality with Carson lens;
2. Build in IR indicator and low battery indicator;
3. IP65 waterproof standard(IP67 optional);
4. Separate manual gain control knob;
5. 30mm diameter eyepiece lens;
6. Longer eye relief 30mm with full FOV;
7. AA battery;
8. Automatic shut off when flipped up;
9. Can fit 3X and 5X magnifier lens;
10. Offer accessories like Sacrificial window, demist shield, rail mount, Tarsier Eclipse, J-arm and mount,
| Gen2+ Image intensifier tube | ||||
|---|---|---|---|---|
| FOM | FOM1400+ | FOM1600+ | FOM1800+ | FOM2000+ |
| SNR(dB) | ≥23 | ≥25 | ≥28 | |
| Resolution(lp/mm) | ≥60 | ≥64 | ≥68 | |
| Gain(cd/m²/lx) | 8000-12000 | 12000-20000 | ||
| Gen3 Image intensifier tube | ||||
| FOM | FOM1200+ | FOM1400+ | FOM1600+ | FOM1800+ |
| SNR(dB) | ≥22 | ≥25 | ≥28 | |
| Resolution(lp/mm) | ≥51 | ≥55 | ≥60 | ≥64 |
| Gain(cd/m²/lx) | 8000-20000 | 11000-20000 | 12000-20000 | |
| Electric | ||||
| Battery type | AA | |||
| Voltage range | 1.2-1.5V | |||
| Switch model | OFF/ON/IR | |||
| Power | ＜0.1W | |||
| Working time | 40H | |||
| IR indicator | Yes | |||
| Low battery indicator | Yes | |||
| Optical | ||||
| Magnification | 1X | |||
| FOV | 40 degree | |||
| Optical distortion | 0.5% Max | |||
| Diopter range | -6 ~ +2SD | |||
| Optical system | F1.2 25mm | |||
| Focus range(M) | 0.25–∞ | |||
| Eye relief | 30mm | |||
| Lens coating | FMC | |||
| Structure | ||||
| Gain control | Manual | |||
| Rotating test | Flip up auto shut off | |||
| Waterproof standard | IP67 | |||
